Enhanced Anti RF-Interference Capability with more Solid RF Performance

Smart-Matched ACCESS & ACCST D16 modes

Built-in 3-Axis Gyroscope & 3-Axis Accelerometer Sensor

Basic Black-Box Data Record Function

Built-in Power Switch Function | Match with Different External Switches (Optional)

12 Configurable Channel Ports* (PWM, SBUS, FBUS, or S.Port)
(Note: In ACCST mode, SBUS Out is assigned on Pin11 & S.Port is on Pin12.)

Supports Signal Redundancy (SBUS In)

Full Control Range with Telemetry (FBUS / S.Port)

Anti-Interference Capability in the Spark-Ignition Process

Over-The-Air (OTA) Firmware Update

External Battery/Device Voltage Detection

Specifications

• Dimension: 48.5×33×17.9mm (L×W×H)
• Weight: 21.3g
• Operating Voltage Range: 3.5 -10V (Recommend 2S Li-Batteries)
• Operating Current: ＜105mA@5V
• Continuous Current: ≤20A (power the device) ｜ Instaneous Current: ≤40A (power the device)
• Voltage Measurement Range via AIN2 (External device): 0-35V (Battery Voltage Divider Ratio: 1:10)
• Antenna connector: IPEX1
• Dual XT30 Power Input Connector
• Compatibility: FrSky 2.4GHz ACCESS / ACCST D16 capable transmitters
• 12 Configurable Channel Ports (ACCESS mode)
  CP1: PWM / SBUS Out / FBUS / S.Port / SBUS In
  CP2-12: PWM / SBUS Out / FBUS / S.Port
• SBUS Out (Supports 16CH / 24CH mode)
